Specify with Precision
Free Revit families and AutoCAD blocks for every InOvate ventilation product. Drop them into your model, get the geometry right the first time, and keep your specifications tight from design through construction.
All files free to download | .RFA & .DWG formats | Last updated: Feb 2026
Dryerbox Models
The Dryerbox recesses the dryer exhaust connection into the wall cavity, protecting the transition duct from crushing and providing cleanout access. Five models cover every framing configuration — 2×4 and 2×6 walls, upward and downward exhaust orientations. Each Revit family includes accurate geometry, connection points, and clearance zones for clash detection.
DryerWallVent Downloads
The DryerWallVent provides a low-profile, high-efficiency exhaust termination at the wall. The Revit family includes the vent body, collar, damper, and secondary back plate — modeled at actual dimensions so wall penetration coordination is accurate from the start.
BIM files for FreshVent, Premium WallVent, and Defender are in development. Check back or contact our engineering team for interim geometry.
DryerJack Models
DryerJack roof vents deliver zero airflow resistance at the termination point. Three models cover different roof configurations. The Revit families include the base flashing, cap, and damper assembly — critical for coordinating penetration locations with the structural and roofing trades.
BIM files for RoofNeck and SoffitFlow are in development.
Dryer-Ell & DryerFlex
The elbows and transition duct that connect the dryer to the in-wall exhaust system are where most equivalent duct length is consumed. The Dryer-Ell carries zero run-length penalty — a significant advantage when modeling tight duct runs. Including these fittings in your BIM model ensures accurate equivalent duct length calculations before the first stud goes up.
Additional Resources
InOvate BIM content is also available through the industry's leading architectural resource platforms. These libraries provide additional file formats, embedded product data, and integration with specification workflows.
Need a file format we don't offer here, or working with a product that doesn't have BIM content yet? Our engineering team builds custom geometry on request. Call us — we pick up on the first ring.
Specifying InOvate?
The InOvate engineering team supports architects and BIM managers with custom cad, specification language, and coordination details.
Talk to Engineering
